DEWALT 12V MAX*/20V MAX*/FLEXVOLT® 4 Amp Charger

Product Overview

The DCB1104 is a versatile 4-Amp charger designed to charge DeWalt’s slide-style lithium-ion battery packs. It serves as an updated, slightly more compact version of the popular DCB115 charger. It features a diagnostic LED system to communicate battery status and is compatible with the entire DeWalt 12V and 20V MAX* lineup.

Compatibility

This charger is compatible with the following DeWalt battery platforms:

• 12V MAX* Lithium-Ion Batteries

• 20V MAX* Lithium-Ion Batteries

20V/60V MAX FLEXVOLT®* Batteries (will charge them at the 4-Amp rate)

Key Features

• Two-Stage LED Indicator: Communicates the battery’s status:

  • Blinking Green: Charging.

  • Solid Green: Fully Charged.

  • Red Flashing (Fast): Replace Pack (Damaged Battery).

  • Red Flashing (Slow/Pulse): Hot/Cold Delay (Battery is too hot or cold to charge safely).

• Compact Size: It is approximately 15% smaller than the previous DCB115 4 Amp charger, saving space on your workbench.

• Smart Charging: Diagnoses battery condition to prevent damage and optimize battery life.



  Specification	Detail
  Voltage	12V MAX* / 20V MAX*
  Output Current	4 Amps (DC)
  Input Voltage	120V AC (Standard US Plug)
  Charge Time	~1 Hour (for standard 4Ah batteries, varies by capacity)
  Mounting	Wall mountable (requires 2 screws, sold separately)
  Item Weight	1.08 lbs (0.49 kg)
  Dimensions	6″ L x 4″ W x 2.75″ H(Approx.)

Warranty & Service

• 3-Year Limited Warranty

• 1-Year Free Service Contract

• 90-Day Money-Back Guarantee

*Note: “20V MAX” refers to the maximum initial battery voltage (measured without a workload), which is 20 volts. Nominal voltage is 18 volts.
